Electric Golf Cart Charger
LITHIUM Battery Charger
Model#PES015/EVLI
Salient Features
Wide Input AC Voltage Range 170V-300V.
High efficiency, less power consumption.
Accurate Battery Charging Current Limit.
Overload protection
Battery reverse polarity protection .
Specially designed to meet Indian power condition.
CC-CV Charging mode.
Zero voltage start-up available.
With Microcontroller .
Over temperature shutdown with auto recovery
Specifications
Ac Voltage : 180-320 VAC~
Output over Protection : Yes
Auto Cut Mode : Yes
Visual LED Indication : 4 Led Bar Graph
Charging Mode : CC-CV
Outer enclosure Material : Aluminum
Dimensions : L=245mm, W=150mm, H=90mm
Weight : 3.5Kg
Available Model
48V 20A
48V 17A
60V 15A
72V 12A
(Maximum DC Output Voltage as per customer requirement)
